Hysteresis Iron Cobalt Alloy 2J11 Good Corrosion Resistance

Brand Name : XUNSHI

Model Number : 2J11

Certification : ISO 9001:2015

Place of Origin : China

MOQ : 20kg

Price : Negotiable

Payment Terms : T/T, Western Union

Supply Ability : 300 kg per week

Delivery Time : 45-60 days

Packaging Details : Plywood case

Form of supply : Cold rolled strip

Thickness : 0.05-0.8mm

Width : 5-200mm

Product Name : Permanent Magnet Alloy

spec : GB/T 14988-2008

Contact Now

Iron Cobalt Hysteresis Alloy 2J11 Good Corrosion Resistance

2J11 is a deformable permanent magnetic alloy with good properties, capable of forging, rolling and drawing and cutting processing.

The 2J11 alloy has good hysteresis performance within 2~5kA/m and good processing performance before tempering. Changing the tempering temperature can change the working magnetic field in a wide range.

Chemical compositions

elements C P S Si Mn Co V Ni Fe
% ≤0.12 ≤0.025 ≤0.020 ≤0.70

≤0.70

 51.0~53.0 10.5~11.5

≤0.70

 Balance

Magnetic performance:

Hμ/(kA/m)

(Hμ/Oe)

Bμ/T

(Bμ/Gs)

 Pμ/(104J/m3) Kμ
≥

16.0-20.8

(200-260)

0.9-1.2

(9000-12000)

 3.5 0.57

Physical properties:

Density:8.1g/cm3

Melt temperature: 1530 °C-1600 °C

Curie temperature: 860 °C

Restivity: 0.77 Ω·m


Application: Magnetic motor rotor, Magnetic brake

The corrosion resistance of 2J11 is good and it does not rust in the atmosphere.

2J11 alloy is supplied at Cold-rolled state without heat treatment.

Thickness:0.05-1.0mm

With:5-200mm

We can also supply the other products of 2J11,such as forgings and processed parts according to the customer needs.

Hysteresis Iron Cobalt Alloy 2J11 Good Corrosion Resistance

Hysteresis Iron Cobalt Alloy 2J11 Good Corrosion ResistanceHysteresis Iron Cobalt Alloy 2J11 Good Corrosion Resistance
