2J4 Iron-Cobalt Hysteresis Permanent Magnet Alloy Corrosion resistance
2J4 is a Iron-Cobalt-Nickel-Vanadium hysteresis alloy which combines the advantage of high hysteresis loss and low magnetizing force.
It exhibits the highest efficiency(loss per unit magnetizing force) of any known material. That is why it is widely used in hysteresis motor applications.
2J4 belongs to Iron-Cobalt Permenent Magnetic Alloy,this alloy is suitable for making high efficiency hysteresis motor rotor with high operating temperature, and this alloy does not cause reduced magnetic performance in the range of + 150~ -140 ℃. In all kinds of the Magnetic Alloys, 2J4 is the one with a long application time and a large dosage. We can supply cold rolled strip of 2J4 alloy with mature process and stable quality in thickness range 0.05-1.0mm.
.Density of 2J4: 8.2g/cm 3
Machenical properties
Good plasticity before tempering
General Welding performance
Good magnetic stability
Corrosion resistance properties
Good forming performance after continuous rolling
Standards
GB/T 14988-1994
The available forms
Cold rolled strip in thickness range 0.05-1.0mm.
Other thickness also availble per request.
Chemical composition
| C | ≤0.12 |
| P | ≤0.025 |
| S | ≤0.02 |
| Si | ≤0.70 |
| Mn | ≤0.70 |
| Co | 44.0~46.0 |
| V | 3.5~4.5 |
| Ni | 5.30~6.70 |
| Fe | Balance |
Advantages
High hysteresis loss
Low magnetizing force
Highest efficiency (loss per unit magnetizing force) of any known material
Application
Magnetic motor rotor, Magnetic brake
